Nidec Unidrive M702 User Manual

Model
Heavy Duty Normal Duty
Kc
Rated
Current
Motor Shaft Power
Peak
Current
Open Loop
Peak
Current RFC
Rated
Current
Motor Shaft Power
Peak
Current
A kW hp A A A kW hp A A
05500030 3 1.5 2 4.5 6 3.9 2.2 3 4.29 6.667
05500040 4 2.2 3 6 8 6.1 4 5 6.71 8.889
05500069 6.9 4 5 10.35 13.8 10 5.5 7.5 11 15.333
06500100 10 5.5 7.5 15 20 12 7.5 10 13.2 22.222
06500150 15 7.5 10 22.5 30 17 11 15 18.7 33.333
06500190 19 11 15 28.5 38 22 15 20 24.2 42.222
06500230 23 15 20 34.5 46 27 18.5 25 29.7 51.111
06500290 29 18.5 25 43.5 58 34 22 30 37.4 64.444
06500350 35 22 30 52.5 70 43 30 40 47.3 77.778
07500440 44 30 40 66 88 53 45 50 58.3 97.778
07500550 55 37 50 82.5 110 73 55 60 80.3 122.222
08500630 63 45 60 94.5 126 86 75 75 94.6 140
08500860 86 55 75 129 172 108 90 100 118.8 191.111
09501040 104 75 100 156 182 125 110 125 137.5 202.222
09501310 131 90 125 196.5 229.25 150 110 150 165 254.722
10501520 152 110 150 228 266 200 130 200 220 295.556
10501900 190 132 200 285 332.5 200 150 200 220 369.444
11502000 200 150 200 300 350 248 175 250 272.8 388.889
11502540 254 185 250 381 444.5 288 225 300 316.8 493.889
11502850 285 225 300 427.5 498.75 315 250 350 346.5 554.167
690V Rated Drives
Model
Heavy Duty Normal Duty
Kc
Rated
Current
Motor Shaft Power
Peak
Current
Open Loop
Peak
Current RFC
Rated
Current
Motor Shaft Power
Peak
Current
A kW hp A A A kW hp A A
07600190 19 15 20 28.5 38 23 18.5 25 25.3 42.222
07600240 24 18.5 25 36 48 30 22 30 33 53.333
07600290 29 22 30 43.5 58 36 30 40 39.6 64.444
07600380 38 30 40 57 76 46 37 50 50.6 84.444
07600440 44 37 50 66 88 52 45 60 57.2 97.778
07600540 54 45 60 81 108 73 55 75 80.3 120
08600630 63 55 75 94.5 126 86 75 100 94.6 140
08600860 86 75 100 129 172 108 90 125 118.8 191.111
09601040 104 90 125 156 182 125 110 150 137.5 202.222
09601310 131 110 150 196.5 229.25 155 132 175 170.5 254.722
10601500 150 132 175 225 262.5 172 160 200 189.2 291.667
10601780 178 160 200 267 311.5 197 185 250 216.7 346.111
11602100 210 185 250 315 367.5 225 200 250 247.5 408.333
11602380 238 200 250 357 416.5 275 250 300 302.5 462.778
11602630 263 250 300 394.5 460.25 305 315 400 335.5 511.389
Unidrive M702 Parameter Reference Guide
