Nidec Unidrive M702 User Manual

Current Ratings
The tables below give the maximum output current ratings, peak current ratings and power ratings for all drive sizes and voltage ratings.
200V Rated Drives
Model
Heavy Duty Normal Duty
Kc
Rated
Current
Motor Shaft Power
Peak
Current
Open Loop
Peak
Current RFC
Rated
Current
Motor Shaft Power
Peak
Current
A kW hp A A A kW hp A A
03200050 5 0.75 1 7.5 10 6.6 1.1 1.5 7.26 11.111
03200066 6.6 1.1 1.5 9.9 13.2 8 1.5 2 8.8 14.667
03200080 8 1.5 2 12 16 11 2.2 3 12.1 17.778
03200106 10.6 2.2 3 15.9 21.2 12.7 3 3 13.97 23.556
04200137 13.7 3 3 20.55 27.4 18 4 5 19.8 30.444
04200185 18.5 4 5 27.75 37 25 5.5 7.5 27.5 41.111
05200250 25 5.5 7.5 37.5 50 30 7.5 10 33 55.556
06200330 33 7.5 10 49.5 66 50 11 15 55 73.333
06200440 44 11 15 66 88 58 15 20 63.8 97.778
07200610 61 15 20 91.5 122 75 18.5 25 82.5 135.556
07200750 75 18.5 25 112.5 150 94 22 30 103.4 166.667
07200830 83 22 30 124.5 166 117 30 40 128.7 184.444
08201160 116 30 40 174 232 149 37 50 163.9 257.778
08201320 132 37 50 198 264 180 45 60 198 293.333
09201760 176 45 60 264 308 216 55 75 237.6 342.222
09202190 219 55 75 328.5 383.25 266 75 100 292.6 425.833
10202830 283 75 100 424.5 495.25 325 90 125 357.5 550.278
10203000 300 90 125 450 525 360 110 150 396 583.333
400V Rated Drives
Model
Heavy Duty Normal Duty
Kc
Rated
Current
Motor Shaft Power
Peak
Current
Open Loop
Peak
Current RFC
Rated
Current
Motor Shaft Power
Peak
Current
A kW hp A A A kW hp A A
03400025 2.5 0.75 1 3.75 5 3.4 1.1 1.5 3.74 5.556
03400031 3.1 1.1 1.5 4.65 6.2 4.5 1.5 2 4.95 6.889
03400045 4.5 1.5 2 6.75 9 6.2 2.2 3 6.82 10
03400062 6.2 2.2 3 9.3 12.4 7.7 3 5 8.47 13.778
03400078 7.8 3 5 11.7 15.6 10.4 4 5 11.44 17.333
03400100 10 4 5 15 20 12.3 5.5 7.5 13.53 22.222
04400150 15 5.5 10 22.5 30 18.5 7.5 10 20.35 33.333
04400172 17.2 7.5 10 25.8 34.4 24 11 15 26.4 38.222
05400270 27 11 20 40.5 54 30 15 20 33 60
05400300 30 15 20 45 60 31 15 20 34.1 66.667
06400350 35 15 25 52.5 70 38 18.5 25 41.8 77.778
06400420 42 18.5 30 63 84 48 22 30 52.8 93.333
06400470 47 22 30 70.5 94 63 30 40 69.3 104.444
07400660 66 30 50 99 132 79 37 50 86.9 146.667
07400770 77 37 60 115.5 154 94 45 60 103.4 171.111
07401000 100 45 75 150 200 112 55 75 123.2 222.222
08401340 134 55 100 201 268 155 75 100 170.5 297.778
08401570 157 75 125 235.5 314 184 90 125 202.4 348.889
09402000 200 90 150 300 350 221 110 150 243.1 388.889
09402240 224 110 150 336 392 266 132 200 292.6 435.556
10402700 270 132 200 405 472.5 320 160 250 352 525
10403200 320 160 250 480 560 361 200 300 397.1 622.222
11403770 377 185 300 565.5 659.75 437 225 350 480.7 733.056
11404170 417 200 350 625.5 729.75 487 250 400 535.7 810.833
11404640 464 250 400 696 812 507 315 450 557.7 902.222
575V Rated Drives
8
Unidrive M702 Parameter Reference Guide
Issue: 01.16.01 (Eth 01.07.00)
