5 Installation and connection
14/23 OPERATING INSTRUCTIONS FOR METAL SOLENOID-VALVES Index: 0
5 Installation and connection
5.1 Preparing the installation
5.1.1 Checking conditions of use
§ Make sure that the valve design is suitable for the intended use:
- Materials used
- Medium
§ Ensures the necessary conditions of use
- The resistance of the materials used for the body and seals against the medium
- Media temperature
- Operating pressure
§ Agree any other use with the manufacturer
5.2 Planning pipelines
5.2.1 Designing pipelines
Danger of poisoning and environmental damage from the medium
Leakage due to leaks caused by impermissible pipeline forces.
Make sure that no tensile or compressive forces and no bending
moments act on the armature.
§ Plan pipelines with safety in mind
- Ensure there are no tensile or compressive forces
- Ensure there are no bending moments
- Compensate for changes in length caused by temperature fluctuations
- Observe the direction of flow
- Pay close attention to the fitting position and direction of the valve
- Apply suitable measures to prevent pressure surges
§ Dimensions (3.3 Design and dimensions)
§ Fit dirt traps to ensure proper functioning
