9 Appendix
22/23 OPERATING INSTRUCTIONS FOR METAL SOLENOID-VALVES Index: 0
9 Appendix
9.1 Technical data
Please refer to the data sheet for technical data such as the operating pressure or the operating
temperature. If the data sheet is not available, request it from the manufacturer.
9.2 Circuit diagrams
9.2.1 Circuit diagrams Type EV01 /-03 and MV01 /-02 /-03
Switching function: NC (normally closed)
9.2.2 Circuit diagrams Type EV04 /-05 /-07, MV04 /-05 /-07 and FV01
Switching function: NC (normally closed)
9.2.3 Circuit diagrams Type EV06 and MV06
Switching function: NC (normally closed)
Switching function: NO (normally open)
9.2.4 Circuit diagrams Type EV08 /-09 and MV08 /-09
Switching function: NC (normally closed)
A
P
A
P
A
P
A
P
A
P
R
