F2.08
Set hopping frequency, hopping
frequency range
Hopping frequency
0.00
○
F2.09
Hop frequency range
0.00~Upper limit
frequency
0.00
○
F2.10
Torque lift setting
The amount of manual torque increase,
which is set relative to the Percentage of
motor rated voltage.
0.0～30.0％
Model
Settings
×
F2.11
Torque lift cutoff
frequency
0.00~Motor rated frequency.。
15.00
×
F2.12
The set frequency is below
the lower limit frequency
Rate-time action
0: Operate at the lower frequency limit
1:Zero frequency operation
2: Shutdown
0～2
0
×
F2.13
FDTHorizontal Setting
10.00
○
F2.14
FDTHysteresis value
1.00
○
F2.15
Frequency arrival
FARDetectionWidth
Positive and negative detection width of
output frequency at set frequency
Internal and Terminal Output Valid
Signal (Low level).
5.00
○
F2.16
Multi-speed
frequency 0
5.00
○
F2.17
10.00
○
F2.18
15.00
○
F2.19
20.00
○
F2.20
25.00
○
F2.21
37.50
○
F2.22
50.00
○
F2.23
0.00
○
F2.24
0
○
F2.25
Shutdown Monitoring
Parameter Item
Selection
0～31
1
○
By cha nging the setting value of the
func tion code, it can be changed
Moni toring items in the main
moni toring interface, such as
sett ing4, I.e., select the output
curr entD-04The default display item
n the ma in monitoring interface is the
curr ent output current value
0～31
F2.26
Display Mode
LED Bits: Adjust the frequency, PID Display
selection for given amount
0: Display frequency, PID Quantity given
1: Show only status monitoring parameters
LED Ten: Reserved
LED Hundred: Reserved
LED Thousands: Reserved
0-0001H
0
○
F2.27
0: Invalid 1: Effective
0～1
0
○
F2.28
In case of motor oscillation, set F2.28 to select
effective, turn on the oscillation suppression
function, and then adjust by setting the
oscillation suppression coefficient. Generally,
The oscillation amplitude is large, and the
oscillation suppression coefficient is increased
by F2.29
0～1000
100
○
F2.29
Cooling Fan Control
0: Automatic control mode
1: The power-on process runs all the time
2. Fan action with temperature higher
than 50 ℃The fan does not operate
below 45 ℃.
0～2
0
○
F2.30
PWM Mode Selection
0: full frequency seven segments
1: Full-frequency five-band
2: 7 to 5
0～2
0
×
F2.31
AVR Functions
0: Invalid
1: The whole process is effective
2: Invalid only when decelerating
0～2
2
×
F2.32
Parameter
Initialization
0: No action
1: All user parameters are restored to
factory settings
2: clear fault record
0～2
0
×
F G r o u p 3 - I n p u t / O u t p u t Te r m i n a l s
0: The control end is idle
1: Forward Rotation Control (FWD)
2: Inversion Control (REV)
3: Three-wire operation control
4: Forward rotation inching control
5: Reverse inching control
6: frequency increment instruction (UP)
7: Frequency Decrease Command
(DOWN)
8: Free shutdown control
9: External Reset Signal Input (RST)
10: Reserved
11: External Fault Normally Open Input
: Multi-speed selection S1
: multi-speed selection S2
: multi-speed selection S3
15-17: retain
: frequency source switch
19: UP/DOWN frequency clear
20: run command channel force to
terminal
21: Acceleration and deceleration are
prohibited
22: to 47: retain
48: external shutdown signal input (STOP)
49: Stop DC Brake Command
50: Reserved
51: run command channel force to
communication
52-61: retain
F3.00
Input Terminal X1
Function
0～51
1
×
F3-01
0～51
2
×
F3.02
0～51
0
×
F3.03
0～51
0
×
F3.04～
F3.05
Reservation
—
— —
◆
F3.06
FWD/REV Terminal
Control Mode
0: 2-wire control mode 1
1: 2-wire control mode 2
2: 3-wire control mode 1
3: 3-wire control mode 2
0～3 0
×
-10-
-9-
Function
Code
N a m e
C o n t e n t
S e t R a n g e
Factor y
Sett ings
Change
Function
Code
N a m e
C o n t e n t
S e t R a n g e
Factor y
Sett ings
Change
0.00~Upper limit
frequency
0.00~Motor rated
frequency.。
0.00 Hz~Upper limit
frequency
0.00 Hz~Upper limit
frequency
0.00~Upper limit
frequency
-Upper limit frequency
~ up Limited frequency
-Upper limit frequency
~ up Limited frequency
-Upper limit frequency
~ up Limited frequency
-Upper limit frequency
~ up Limited frequency
-Upper limit frequency
~ up Limited frequency
-Upper limit frequency
~ up Limited frequency
-Upper limit frequency
~ up Limited frequency
-Upper limit frequency
~ up Limited frequency
Multi-speed
frequency 1
Multi-speed
frequency 2
Multi-speed
frequency 3
Multi-speed
frequency 4
Multi-speed
frequency 5
Multi-speed
frequency 6
Multi-speed
frequency 7
Set multi-speed frequency 0
Set multi-speed frequency 1
Set multi-speed frequency 2
Set multi-speed frequency 3
Set multi-speed frequency 4
Set multi-speed frequency 5
Set multi-speed frequency 6
Set multi-speed frequency 7
Operation Monitoring
Parameter Item
Selection
Oscillation suppression
selection
Oscillation suppression
coefficient
Input Terminal X2
Function
Input Terminal X3
Function
Input Terminal X3
Function
FDT Horizontal set value
FDT lagged value
time
time
