nifty Heightrider HR21 - 3.5 Torque Requirements

HR Series
Operating & Safety Instructions
English/USA – 11/09
Original Instructions
21
3.5 TORQUE REQUIREMENTS
SCREW QUALITY/SIZE Tightening torque in ft lbs (Nm)
Grade 8.8 10.9
M 6 7.0 (10) 10 (14)
M 8 19 (25) 26 (35)
M 10 36 (49) 51 (69)
M 12 63 (86) 89 (120)
M 14 99 (135) 140 (190)
M 16 155 (210) 218 (295)
M 18 214 (290) 300 (405)
WHEEL NUTS 110ft lbs 150Nm
WHEEL MOTOR NUTS 99ft lbs 135Nm
SLEW RING BOLTS 220ft lbs 300Nm
