nifty Heightrider HR21 - 1.5 General Specifications

HR Series
Operating & Safety Instructions
English/USA – 11/09
Original Instructions
4
1.5 GENERAL SPECIFICATION
FEATURE HR21 (SP64) HYBRID AWD
MAXIMUM HEIGHT - WORKING 20.66m
67ft 9in
MAXIMUM HEIGHT - PLATFORM 18.70m
61ft 4in
MAXIMUM OUTREACH 12.60m
41ft 4in
MAXIMUM HEIGHT – STOWED 2.15m
7ft
MAXIMUM WIDTH 2.25m
7ft 5in
MAXIMUM LENGTH – STOWED 5.00m
16ft 5in
PLATFORM CAPACITY - Europe 225kg (500lbs)
WHEELBASE 2.30m
7ft 6in
TURNING RADIUS – OUTSIDE 3.97m
13ft
TURRET ROTATION 355
0
TURRET TAIL SWING 0.49m
1ft 7in
TRAVEL SPEED (2WD) (AWD)
0 – 2.8mph 0 - 1.4mph
0 – 4.5kph 0 – 2.25kph
PLATFORM SIZE 1.80m x 0.70m
5ft 11in x 2ft 2in
CONTROLS Proportional electric over hydraulic
HYDRAULIC PRESSURE 280bar
TYRES Solid
GRADEABILITY 40%
MINIMUM VEHICLE WEIGHT 6,300kg
13,889lb
MAXIMUM GROUND PRESSURE 0.1065kn/cm
2
22,244lb/ft
2
POWER SOURCE
DE (Diesel & Battery) - Kubota 722 engine and
8 x 6v 350 AH batteries
