Nikon 1 S1 Reference Manual

132
i
4
Focus.
Rotate the multi selector until the sub-
ject is in focus. Rotate the multi selec-
tor clockwise to increase the focus
distance, counterclockwise to
decrease; the faster you rotate the
multi selector, the quicker the focus
distance changes. The focus indicator
shows the approximate focus dis-
tance. Press J when the subject is in
focus.
Press 1, 3, 4, or 2 to view areas of
the frame not currently visible in the
display; the visible portion is shown
by the navigation window.
Focus indicator
Navigation window
A
Movies
The multi selector can also be used to choose the focus distance if man-
ual focus is selected prior to movie recording. Rotate the multi selector
clockwise to increase the focus distance, counterclockwise to decrease;
the faster you rotate the multi selector, the quicker the focus distance
changes.
A
Focal Plane Position
To determine the distance between your
subject and the camera, measure from the
focal plane mark on the camera body. The
distance between the lens mounting flange
and the focal plane is approximately 17 mm
(0.7 in.).
Focal plane mark
Approx.
17 mm

Nikon 1 S1 Specifications

General

Camera type	Mirrorless
Sensor	CMOS
Effective Pixels	10.1 million
Lens Mount	Nikon 1 mount
Autofocus	Hybrid AF (Phase-detection/Contrast-detect AF)
LCD Screen Size	3.0 inches
LCD Screen Resolution	460, 000 dots
Storage Media	SD/SDHC/SDXC
Battery Life	Approx. 220 shots
Dimensions	102 x 60.5 x 29.7 mm
Sensor Size	13.2 mm x 8.8 mm
ISO Sensitivity	ISO 100-6400
Shutter Speed	1/16000 - 30 sec
Video Recording	Full HD 1080p
Battery	EN-EL20
Weight	240 g (including battery and memory card)
