256
En
Es
Fr
De
It
Sv
Nl
Ru
Pl
Fi
No
Dk
Cz
Ro
Hu
Kr
사양
측정 범위 (실제 거리)
5 - 730 m/6 - 800 yd.
거리 표시 (증분)
1 m/yd.
정확도 (실제 거리)
*1
±1 m/yd.100 m/yd. 보다 짧은 경우)
±2 m/yd.100 m/yd. 이상인 경우)
배율 (×) 6
효과적인 대물렌즈 지름 (mm)
20
관측 시야각 (실제) (˚)
6.0
사출동공 거리 (mm)
16.7
사출동공 (mm)
3.3
디옵터 조정 ±4 m
-1
치수 (길이 × 높이 × ) (L × H × W)
(mm/in.)
91 × 73 × 37/3.6 × 2.9 × 1.5
중량 (g/oz.) 130/4.6 (건전지 제외)
작동 온도 (˚C/˚F) -10 +50/14 122
작동 습도 (%RH) 80이하 (결로 없이)
전력원
CR2 리튬 건전지 × 1 (DC 3V)
자동 전원 꺼짐 (비작동 8 )
구조
방우
*2
전자파 적합성
FCC Part15 SubPartB 등급 B, EU:EMC 지침, AS/NZS, VCCI 등급 B,
CU TR 020, ICES-003
환경 RoHS, WEEE
레이저 분류
IEC60825-1: 등급 1M/레이저 제품
FDA/21 CFR Part 1040.10: 등급 I 레이저 제품
파장 (nm) 905
펄스 지속시간 (ns)
20
기술적 노트

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nikon COOLSHOT 20 GII and is the answer not in the manual?

Nikon COOLSHOT 20 GII Specifications

General IconGeneral
Exit pupil3.3 mm
Eye relief16.7 mm
Wavelength905 nm
Laser class1M
Magnification6 x
Measurement range5 - 730 m
Objective diameter20 mm
Real field of view6 °
Measurement accuracy- 1 - 1 m
Diopter adjustment (D-D)-4 - 4
Sustainability complianceYes
Sustainability certificatesRoHS, WEEE
Units of measurementm, yd
Product colorBlack, White
Battery typeCR2
Battery voltage3 V
Battery technologyLithium
Number of batteries supported1
Operating temperature (T-T)-10 - 50 °C
Weight and Dimensions IconWeight and Dimensions
Depth91 mm
Width37 mm
Height73 mm
Weight130 g
