Applications 4
Pulse Laser Station NPL-302 Series Instruction Manual 85
6.
To record the point, press [ENT]. PT defaults to
the specified PT + 1000.
After recording the point, the display returns to
the observation screen. When you press
[ESC], the
display returns to the PT/CD/R input screen. If
you entered the stakeout point using a single point
name, the PT defaults to the last PT + 1.
If you selected a point from the list, the display
returns to the list, unless all points have been
selected. Press
[ESC] to return to the point input
screen.
To switch between display screens, press [DSP]. This function works as in the angle-
distance stakeout, except that the screen counter (for example, S-O1/8) is not
displayed. For more information, see Using [DSP] to switch between display
screens, page 83.
Once a measurement is taken, the Cut/Fill value and Z coordinate are updated as
the VA is changed.
Use the Add Constant field in MENU >
Settings > Stakeout
to specify an
integer that is added to the point number being
staked to generate a new number for recording
the staked point. The default value is 1000. For
example, when you stake out PT3 with an Add
Constant of 1000, the default number for SO
record is 1003. For more information, see
Stakeout, page 138.
