2 Preparation
10 Pulse Laser Station NPL-302 Series Instruction Manual
Unpacking and Packing the Instrument 2.1
Note – Handle the NPL-302 series instrument gently to protect it from shocks and
excessive vibration.
Unpacking 21.1
To unpack the instrument, grip the carrying
handle and gently remove the instrument
from the carrying case.
Packing 21.2
Note – Store the instrument with the battery
pack attached.
To pack the instrument back into the carrying
case:
1. Set the telescope in the horizontal face-1 position.
2. Align the W storage mark on the bottom of
the face-1 keyboard with W the mark on the
leveling base clamp knob.
3. Lightly fasten the clamp knobs.
4. Place the instrument in the carrying case.
Note – When packing the charger (Q-75U/E) in
the plastic carrying case, make sure that you
store it as shown on the sticker inside the case.
Make sure that the battery charger cable is not
pinched when you close the case cover.
Charging and Discharging the Battery Pack 2.1
Before charging the battery pack, read the warnings (also listed in the Safety section
at the front of this manual) and the following notes.
C
Warning – Use only the specified battery charger (part number Q-75U/E) to
charge the battery pack (part number BC-65). Using other chargers, such as
a charger with part number Q-7U/E or Q7C, may cause the battery pack to
catch fire or rupture.
