NILES AUDIO CORPORATION – 1-800-BUY-HIFI – 1-305-238-4373
11
Figure 3
Existing
Transformer
Existing
Doorbell Button
Existing Chime
DBI-2
3-30VTrigger
DBI-2
wIRING LEGEND
Single Conductor
