Niles dbi-2 - Installation Settings: Custom Chime Details; DBI-2 Recording Custom Chime 1; DBI-2 Recording Custom Chime 2; DBI-2 Specifications

NILES AUDIO CORPORATION – 1-800-BUY-HIFI – 1-305-238-4373
SPECIFICATIONS
Audio
Chime:100Hz~3kHz,+/-3dB
AudioPassThrough:20Hz~20kHz,+/-0.5dB
Trigger Inputs
VoltageTriggerInput:3V-30VAC/DC
ContactClosureInputs:<10ohms
Power Supply
Input:100-240VAC50-60Hz0.5A
Output:12VDC1.25A
Unit Dimensions
7-7/8" W x 4-1/8" H x 1" D
20cmWx10.5cmHx2.5cmD
15
INSTALLATION SETTINGS (Continued)
RECORDING CUSTOM ChIME 1
• ConnectyouraudiosourcetotheAUDIOINPUT
connector
• WireatemporarybuttontoContactClosure
1 terminals
• PressandholdtheRECORDCUSTOMCHIMEbutton
• WhileholdingtheRECORDCUSTOMCHIMEbutton
press and release the temporary button
• ReleasetheRECORDCUSTOMCHIMEbutton.The
LED next to the button will now be lit solid red.
• Startplaybackoftheanalogaudiosource.Record-
ing will start automatically. During recording the red
LED will blink.
• TostartrecordingmanuallypresstheRECORD
CUSTOM CHIME button.
• Recordingwillautomaticallystopafter25seconds
• Ifyouwishtostoprecordingearly,pressthe
RECORD CUSTOM CHIME button
RECORDING CUSTOM ChIME 2
• ConnectyouraudiosourcetotheAUDIOINPUT
connector
• WireatemporarybuttontoContactClosure
2 terminals
• PressandholdtheRECORDCUSTOMCHIMEbutton
• WhileholdingtheRECORDCUSTOMCHIME
button, press and release the temporary button
• ReleasetheRECORDCUSTOMCHIMEbutton.The
LED next to the button will now be lit solid green.
• Startplaybackoftheanalogaudiosource.Record-
ing will start automatically. During recording the
green LED will blink.
• Tostartrecordingmanually,presstheRECORD
CUSTOM CHIME button.
• Recordingwillautomaticallystopafter25seconds
• Ifyouwishtostoprecordingearly,pressthe
RECORD CUSTOM CHIME button
