12
INSTALLATION SETTINGS
Contact Closure Triggers - Contact closure trigger inputs provide for two independent chime trig-
gers. Buttons for these triggers may be standard (no light) or lighted. When triggered, the selectable
trigger tone, assigned delay and chime are executed.
3V-30V Voltage Triggers-Voltagetriggerinputsprovidefortwoindependentchimetriggers.When
triggered, the selectable trigger tone, assigned delay and chime are executed. Figure 3
Note: VOLTAGE TRIGGERS ARE NOT POLARITY DEPENDENT AND ARE COMPATIBLE WITH AC AND
DC VOLTAGES
Chime and Audio Level Adjustments - Adjustable output level for the selected chime and the
connected paging system.
Note: THE AUDIO LEVEL ADJUSTMENT DOES NOT AFFECT AN AUDIO INPUT SIGNAL THAT IS BEING
RECORDED FOR A CUSTOM CHIME. THE CUSTOM CHIME LEVEL MUST BE ADJUSTED EXTERNALLY AT THE
AUDIO SOURCE. IMPoRtANt: ADJUSTING THE CHIME AND AUDIO LEVEL MAY IMPROVE SOUND QUALITY.
