Niles SVL-2 - Installation; Wiring Diagram

Installation
1. Select a convenient location for the SVL-2.
2. Run all the necessary wiring to the SVL-2. Label the wires for
future reference. See (Figure 2).
8
S PEAKER S ELECTION /V OLUME C ONTROL S YSTEM
Figure2
Wiring Diagram
TUNER 94.9
15
SPEAKER 2 SPEAKER 1
LR
AMPLIFIER
LRLR
++
--
++
--
Niles Audio
Corporat
ion, Inc.
Miami, Flor
ida USA
NILES
Niles SVL-2
Receiver
Speaker
Pair 2
Speaker
Pair 1
