13
D
Service / Repair.
Fig. 1
Dismounting / mounting of the pump.
1. Loosen the 4 screws that are on top of the pump (fig. 1) then the pump can be opened
(fig. 2).
Note that some oil might come out when opening the pump!
2. Fig. 3 is an overview of the parts in the cylinder block.
Fig. 2
Fig. 3
