Service / Repair.

Fig. 1 Fig. 2

Dismounting / mounting of motor cover.

 After placing the MPU in the cabinet, next is to mount the fan cover. Be sure that it is

fixed in the right position in both sides (fig. 1)

 Then the water protection plate is mounted in the two grooves (fig. 2)

The capacitor must be fixed to the cabinet with a cable binder as shown on fig 3.

Fig. 3
