Service / Repair.
NOTE:
When mounting the front cabinet first step is to slide the cabinet down (fig. 1) in the
grooves (fig. 2) making sure that all grooves are fitted together.
Then the accessories storage must be mounted. It is in the right position when the front
cabinet and the accessories storage are clicked together, this must be done before to
mount the screws.
Last step after all is assembled is to mount the water outlet protection (fig. 3). This can
easily be mounted by lightly pushing it in with the hand (fig. 4).
Fig. 1 Fig. 2
Fig. 3 Fig. 4
