A-10 FM810 ST, FM810 XP - 56091150 2/2015
INSTRUCTIONS FOR USEA - ENGLISH
TROUBLESHOOTING
Problem Cause Action
Motor will not start. No power.
Switch Lever Safety Lock Button (2) not
depressed
Defective switch / Faulty connection
Check power supply and connection
Depress Switch Lever Safety Lock Button (2)
before activating Switch Levers (3).
Contact an authorized Advance Dealer.
Motor fails to start / runs sluggish. Low voltage from excessive length or
undersized extension cord.
Defective start capacitor.
Defective start switch.
Defective start/run capacitor
Defective motor low voltage
Use a 12 Ga extension cord, not to exceed
50’ length.
Contact an authorized Advance Dealer.
Contact an authorized Advance Dealer.
Contact an authorized Advance Dealer.
Contact an authorized Advance Dealer.
Fuse / Circuit Breaker repeatedly trips. Low voltage.
Bad connection.
Defective motor.
Eliminate extension cord. Locate power
source closer to work site. Have voltage
checked by a qualifi ed electrician.
Contact an authorized Advance Dealer.
Contact an authorized Advance Dealer.
TECHNICAL SPECIFICATIONS (as installed and tested on the unit)
Model FM810 ST FM810 XP
Model Number 56105614 56105616
Electrical 1.5HP - 115V/60Hz 1.5HP - 115V/60Hz
Pad/Brush Speed 3540 rpm 3540 rpm
Pad/Brush Size 14” x 20” (355mm x 508mm) 14” x 20” (355mm x 508mm)
Total Weight (w/cord) 160.5 lbs. (72.8 kg) 171 lbs. (77.5 kg)
Sound Pressure Level (ISO 11201) 69dBA 69dBA
Protection Grade IPX0 IPX0
Protection Class
Material Composition and Recyclability
Type % of machine weight % recyclable
Aluminum 1% 100%
Electrical / motors / engines - misc 38% 70%
Ferrous metals 52% 100%
Harnesses / cables 6% 67%
Liquids 0% 0%
Plastic - non-recyclable 2% 0%
Plastic - recyclable 1% 100%
Polyethylene 0% 0%
Rubber 1% 100%
