Optional accessories / Option depending on model
Original instruction
13
Specifications
MH
4M-180/950 TROST 4M-200/1050 XP
4M-90/770 X
4M-90/770
Voltage 110 V / 1~ / 50 Hz
Voltage 220 V / 1~ / 60Hz
Voltage 230 V / 1~ / 50Hz GB
Voltage 400 V / 3~ / 50Hz EU EU
Voltage 230-400 V/ 3~ / 50Hz NO,BE NO,BE
Voltage 220-460 V/ 3~ / 60Hz
Fuse A
16 EU
25 NO,BE
1 6 E U
25 NO,BE
13
Power rating kW 6,9 7,9 3
Power consumption A 21.7 24 13
Type of protection IP X5
Working pressure bar (Mpa) 180 (18) 200 (20) 90
Permissible pressure bar (Mpa) 135
Volume fl ow (max) l/h 950 1050 770
Volume fl ow Q
IEC
l/h 900 1000 720
High pressure nozzle NT0550 NT0500 NT0650
Permissible temperature °C 80 - 140
Max. water inlet temperature °C 40
Max. water inlet pressure bar (Mpa) 10 (1)
Dimensions l x w x h mm 1053 x 687 x 760
Weight kg 145 128/133
Noise level at a distance of
1 m EN 60704-1
dB(A) 76.6 76.9 72,4
Sound power level LW
A
dB(A) 93 93 88
Vibration ISO 5349 m/s² ≤ 2,5
Recoil forces N 49 56 27
Heating capacity kW 70 70 55
Fuel tank l 15
Detergent tank A / B l 10
Oil quantity l 1
Oil type SAE 15 W 40
