FORM NO. 56041423 / SD 4317, SD 5120 - 6
AFTER USE
1 Unplug the Power Cord, coil it and hang it from the Operator Handle
Grips.
2 Remove the pad holder or brush from the machine. Clean the pad or
brush and hang it up to dry. Allow buffing pads to dry completely
before using again.
3 Store brushes and pad holders separate from the machine. Never
store the machine with the pad holder or brush on the machine.
4 Wipe the entire machine with a clean, damp cloth. Wipe the under-
side of the brush housing after wet use.
5 Inspect the entire machine and all accessories for damage. Perform
any required maintenance or repairs before storage.
6 Store the machine in a clean, dry place with the Handle locked in the
upright position.
TROUBLESHOOTING
SWIRLS ON THE FLOOR AFTER SCRUBBING
• Floor not clean.
• Incorrect solution.
• Area not properly swept - debris in pad or brush.
• Improper pad or brush for the job.
• Moving the machine too fast.
SWIRLS ON THE FLOOR AFTER DRY BUFFING
• Moving the machine too fast.
• Floor finish too soft.
• Area not properly swept - debris in pad or brush.
• Improper pad or brush for the job.
CIRCLES ON THE FLOOR
• Machine standing still while the brush or pad is running.
FLOOR FINISH REMOVED
• Improper pad... too aggressive.
• Solution too strong.
MACHINE WOBBLES DURING OPERATION
• Defective pad... one side is more dense than the other.
• Machine left sitting on brush or pad for extended period of time
causing bristles or pad to “take a set”.
• Pad not “seated” properly into pad holder bristles.
• Warped block on brush or padholder - replace.
MACHINE DOES NOT RUN
• Check plug for proper connection - on machine and at wall outlet.
• Check building circuit breaker.
• Call for service.
TECHNICAL SPECIFICATIONS (as installed and tested on the unit)
Model SD 4317 SD 5120
Model Number 56201631 56201632
Motor 1.50 hp, 120V 1.50 hp, 120V
Transmission Triple-Planetary Triple-Planetary
Pad/Brush Speed 175 rpm 175 rpm
Pad/Brush Size 17” (43 cm) 20” (51 cm)
Wheels 5” (15 cm) 5” (15 cm)
Cord Length 50’ (15 m) 50’ (15 m)
Base Width 18” (46 cm) 20.75” (53 cm)
Height w/Handle 47” (120 cm) 47” (120 cm)
Net Weight (w/pad holder) 111 lbs (50.34 kg) 115 lbs (52.16 kg)
Shipping Weight (w/pad holder) 115 lbs (52.16 kg) 119 lbs (53.97 kg)
Construction:
Handle Tube Extruded Aluminum Extruded Aluminum
Upper Handle Injection Molded Polypropylene Injection Molded Polypropylene
Base Roto Molded Polyethylene Roto Molded Polyethylene
revised 9/99
