FORM NO. 56041423 / SD 4317, SD 5120 - 8
revised 10/02
HANDLE SYSTEM
Item Ref. No. Qty Description
1 56002098 6 Wsh, Flt SAE 1/4
2 56002292 6 Scr, Pan Phil 1/4-20 x 1.00
3 56002506 1 Scr, Hex Hd 3/8-16 x 5.00
4 56002769 2 Nut, Hex Nyl Loc 3/8-16
5 56002777 1 Scr, Hex Hd 3/8-16 x 7.00
6 56009195 1 Wsh, Flt .40 x 1.25 x .16
7 56009196 1 Wsh, Flt Harden .40 x 1.00 x .16
8 56201015 1 Bracket
9 56201016 2 Bushing
10 Intentionally Omitted
11 56201026 1 Handle Cover
12 56201027 2 Handle Lever
13 56201028 1 Latch Arm
14 56201029 1 Pin
15 56201031 1 Button, Lock
16 56201032 1 Cord Set, 14/3 x 50'
17 56201033 1 Cord Assembly 14/3
18 56201034 1 Switch, N.O. SPST Snap
19 56201054 1 Handle
20 56201056 1 Handle Tube
21 56263648 1 Spring, Plate
22 56382818 1 Strain Relief
23 56016429 1 Decal, Logo
24 Intentionally Omitted
25 56014828 1 Decal, Warning
26 56201592 1 Ball, 1/4 SS
