8 - FORM NO. 56043129 - SR 1900
TECHNICAL SPECIFICATIONS
GeneralSpecicationscommontoAll Models English (Metric)
Dimensions Gas & Propane
Length 93.75 inches (238cm)
Width (minimum)* 64.5 (164cm)
Height 58.5 inches (149cm)
Height w/overhead guard 81.25 inches (206cm)
Height w/cab 79 inches (201cm)
Ground clearance 3.1 inches (7.8cm)
Minimum ceiling height dumping clearance 101.4 inches (257.5cm)
Weights
Gross weight** 4 Cylinder Diesel 3000 lbs. (1360kg)
Gross weight** GM 1.6L 3300 lbs. (1496kg)
Sweep System
Main broom length 50 inches (127cm)
Main broom diameter 14 inches (35.5cm)
Main broom bristle length 3.25 inches (8.26cm)
Sweeping path w/single side broom 65 inches (165cm)
Sweeping path w/dual side brooms 77 inches (196cm)
Side broom diameter (STD) 24 inches (61cm)
Side broom bristle length 6 inches (15.2cm)
Hopper System
Capacity 14 ft
3
(396L)
Lifting capacity 1000 lbs. (454kg)
Dump height (variable) Max. 60 inches (152cm)
Dump height with door open 52.75 inches (134cm)
Dust Control System
Filter type: Pleated paper panel STD (optional poly lter available)
Filter media area 88 ft
2
(8.17m
2
)
Filter dimension 3.19” x 18” x 30” (8.1cm x 45.7cm x 76.2cm)
Dust Guard Water Misting Tank Capacity 14 gal. (53L)
Steering System
Type: Full power steering unit and hydraulic cylinder
Turn radius left 95” (242cm)
Turn radius right 63” (160cm)
Minimum aisle turn width (left) 109 in. (277cm)
Hydraulic System
Oil type: SAE 10W-30 (ll to bottom of screen)
System ll capacity 11 gal. (41.6L)
Engine System
Diesel & Petrol (gasoline) fuel tank capacity 12.5 gal. (47.3L)
Tires
Tire pressure (all 3) 90-100 PSI
*Width (minimum): Width of machine body at the hopper, no side brooms.
**Gross Weight: Standard machine without options, with 175 lbs. operator, with standard sweeping brooms and full tank of fuel.
