FORM NO. 56043123 - SR 1900 - 3
TECHNICAL SPECIFICATIONS
Total Machine Height with Cab
(Refer to Figure 1-1 below.)
79.5 in (202 cm) without Amber Strobe Kit
84.5 in (215 cm) with Amber Strobe Kit installed
System Voltage 12 VDC
Heater Temperature Control Electronic Water Valve w/Bypass
Blower Motors
Heating System
(1) Fasco OEM p/n 2807-510-154, Fasco p/n DC136, 1/8 HP, 4200
RPM, three-speed, 4.5 Amp
A/C System (2) SPAL type 008-A37/C-42D, 4.5 Amp
Refrigerant R-134a, 1.3 lbs.
Condenser Fan Motor SPAL, type VA13-AP9/C-35S, 6.9 Amp
Compressor ICE TM-08-HD, 5 cu. in. (82.0 cc) per revolution, 700-6000 RPM
Compressor Motor
Sauer-Danfoss p/n 121.20.045.00, 1.02 cu. in. (16.7 cc)
displacement
Heating System Capacity 20,000 BTUs/hr.
Air Conditioning System Capacity 13,000 BTUs/hr.
FIGURE 1-1 – SR 1900 Cab Height
