Construction
POSEIDON 7 NEW-C3_en_Ver.1.0_33/12
18
C
Overview Poseidon 7
Pic. C3: Poseidon 7 without cabinet
Pressure gauge
Reed switch
By-pass valve
Cylinder head
Water outlet
Water inlet
Electrical box
Water regulation
D-bearing cover
Detergent valve
ON-OFF switch
Pump oil lid
Pump oil container
Cylinder block
Oil level sensor
