Nilfisk-ALTO SCRUBTEC BOOST 8 Operator's Manual And Parts List

EN
ENGLISH
Nilfisk ALTO Operator's Manual (EN) - SCRUBTEC 866, 871, 866, Boost 8 and 871C - 15 -
How To Install The Brushes Or Pad Drivers On The
Disc Machine
To install the brushes or pad drivers on the machine,
follow this procedure:
1. Turn the key switch "ON".
2. Put the brush head assembly in the "UP" position.
3. Turn the key switch "OFF".
4. Unlatch right and left brush housings and remove
them. See figure 12.
5. Put a brush or pad driver under the brush motor plate.
See figure 13.
6. Align the lugs on the motor gimbal with the slots in the
brush gimbal.
7. Pull the brush up until the gimbal locks.
8. Repeat steps 5, 6 and 7 to install the second brush or
pad driver.
9. Reinstall right and left brush housings and latch front
cover.
DANGER: Operating a machine that is not
completely or fully assembled
could result in injury or property
damage. Do not operate this ma-
chine unless it is completely as-
sembled. Inspect the machine
carefully before operation.
How To Remove The Brushes Or Pad Drivers On the
Disc Machine
To remove the brushes or pad drivers from the machine,
follow this procedure:
1. Turn the key switch "ON".
2. Put the brush head assembly in the "UP" position.
3. Turn the key switch "OFF".
4. Unlatch right and left brush housings and remove
them. See figure 12.
5. Push down on two sides of the brush or pad driver until
the gimbals release.
HOW TO PREPARE THE MACHINE
FOR OPERATION
Figure 12
Figure 13

Nilfisk-ALTO SCRUBTEC BOOST 8 Specifications

General

Brand	Nilfisk-ALTO
Model	SCRUBTEC BOOST 8
Category	Scrubber
Language	English
