Nilfisk-ALTO SCRUBTEC BOOST 8 Operator's Manual And Parts List

EN
ENGLISH
Nilfisk ALTO Operator's Manual (EN) - SCRUBTEC 866, 871, 866, Boost 8 and 871C - 5 -
Model Scrubtec 871 C Scrubtec BOOST 8
Pad / Brush Size (2) 5.75” x 28” (14.6 x 69cm) (2) 14” x 28” (35.6 x 71cm)
Brush Motor (s) (2) .81 hp (.6 kw) (2) 3/4 hp (.56 kw)
613 RPM 2250 RPM
Cleaning Width 28” (71 cm) 28” (71 cm)
Brush Pressure 80 lbs. (36 kg) 1
st
- 65 lbs. (29.5 kg)
2
nd
- 125 lbs. (56.7 kg)
Brush Retention N/A Hook & Loop
Brush Head Side Skirts N/A
Water Retention
Squeegee Width 35” (89 cm) 35” (89 cm)
Width of Machine 30.69” (78 cm) Head 28.75” (73 cm) Head
23.5” (60 cm) Body 23.5” (60 cm) Body
Length of Machine 59.5” (151 cm) 60.5” (154 cm)
Height of Machine 44” (112 cm)
Weight w/250 Ah batteries 792 lbs. (359.3 kg) 794 lbs. (360.2 kg)
and full Solution Tank
Power Supply 24 volt, (4 - 6 volt batteries)
Vacuum Motor .75 hp (550W), 3 stage, tangential discharge
Vacuum Motor Protection Electronic Float Shut-Off
Solution Tank 23 gallons (87 liters)
Solution Fill Rear Fill with Bucket or Hose
Solution Flow 0 - 1 gal/min (0 - 3.8 liters/min) Normal BOOST Scrubbing .12 gal/min (.45 liters/min),
Full range .0 - .65 gal/min (0 -2.5 liters/min)
Recovery Tank 23 gallons (87 liters)
Motor Traction .44 hp (.33 kw)
Speed Forwardward 0 - 260 ft/min (0 - 4.8 km/h)
Speed Reverse 0 - 174 ft/min (0 - 3.2 km/h)
Drive Wheel (2) 10.24” (260 mm) x 3.35” (85 mm) Light Gray, Non-Marking, Foam Filled
Caster (2) 3.94” (10 cm) Polyurethane
Squeegee Material Urethane Front Blade and Rear Blade
Cleaning Grade 2 %
Charger On Board , 24 volt, 25 amp
Vibration @ handle <2.5m/s
2
Sound test @ operator’s ear 71 dBA 63 dBA
Machine Specifications
Model Scrubtec 866 Scrubtec 871 Scrubtec 886
Pad / Brush Size (2) 13” (33 cm) (2) 14” (36 cm) (2) 17” (43 cm)
Brush Motor (s) (2) 3/4 hp (.56 kw) (2) 3/4 hp (.56 kw) (2) 3/4 hp (.56 kw)
200 RPM 200 RPM 200 RPM
Cleaning Width 26” (66 cm) 28” (71 cm) 34” (86.4 cm)
Brush Pressure 1
st
- 80 lbs. (36 kg) 1
st
- 80 lbs. (36 kg) 1
st
- 80 lbs. (36 kg)
2
nd
- 150 lbs. (68 kg) 2
nd
- 150 lbs. (68 kg) 2
nd
- 150 lbs. (68 kg)
Brush Retention Gimbal Gimbal Gimbal
Brush Head Steel Deck w/ Bristle Skirt Steel Deck w/ Bristle Skirt Steel Deck w/Bristle Skirt
Water Retention
Squeegee Width 32.5” (81 cm) 35” (89 cm) 41” (107 cm)
Width of Machine 28” (71 cm) Head 30” (76 cm) Head 35.7” (91 cm) Head
23.5” (60 cm) Body 23.5” (60 cm) Body 23.5” (60 cm) Body
Length of Machine 61” (155 cm) 62” (157 cm) 64” (162 cm)
Height of Machine 44” (112 cm)
Weight w/250 Ah batteries 796 lbs. (361.1 kg) 800 lbs. (362.9 kg) 791 lbs. (358.8 kg)
and full solution tank
Power Supply 24 volt, (4 - 6 volt batteries)
Vacuum Motor .75 hp (550W), 3 stage, tangential discharge
Vacuum Motor Protection Electronic Float Shut-Off
Solution Tank 23 gallons (87 liters)
Solution Fill Rear Fill with Bucket or Hose
Solution Flow 0 - 1 gal/min (0 - 3.8 liters/min)
Recovery Tank 23 gallons (87 liters)
Motor Traction .44 hp (.33 kw)
Speed Forward 0 - 260 ft/min (0 - 4.8 km/h)
Speed Reverse 0 - 174 ft/min (0 - 3.2 km/h)
Drive Wheel (2) 10.24” (260 mm) x 3.35” (85 mm) Light Gray, Non-Marking, Foam Filled
Caster (2) 3.94” (10 cm) Polyurethane
Squeegee Material Urethane Front Blade and Rear Blade
Cleaning Grade 2 %
Charger On Board, 24 volt, 25 amp
Vibration @ handle <2.5m/s
2
Sound test @ operator’s ear 65 dBA 65 dBA 67 dBA
