ADJUSTING THE SADDLE
Adjusting the saddle height
N WARNING
If you pull the seat post too far out of the
seat tube, then the clamp can no longer
secure the seat post sufficiently. The seat
post could come loose or break during the
tour. There is a risk of accident and injury.
Do not pull out the seat post beyond the
minimum insertion depth.
The seat post(1) must always be inserted
at least into seat tube(3).
• Release the seat post clamp (2)
• Do not pull out seat post(1) beyond the
minimum insertion depth.
• Adjust the saddle to the desired hei-
ght. If you put your heel on the pedal
when it is at its lowest point and your
leg is fully stretched, then the saddle is
at the correct height.
• Close the seat post clamp (2).
1
2
4
3
