Ninebot ONE - Removing Foot Pedal Nut; Installing New Washer

19 / 20
10. Use a 21 mm wrench to remove the nut (place a screwdriver into the hole at the bottom of the
pedal to give additional leverage for removing the 21mm Nut).
11. Remove the foot pedal bracket.
12. Install the new flat washer (diameter 16 mm; thickness 2 mm) to the motor shaft, ON TOP of
the existing washers.
Gently use a chisel or
flathead screwdriver to
remove the flat washer.
