Basics
10
Basics
Battery Cover
Remove cover to replace the battery. NOTE: Do not remove the cover
unless you need to replace the battery or check battery installation.
Volume / Screen Brightness Control
Adjust the sound volume or the brightness of the screens.
Stylus Holder
Always replace the stylus into the stylus holder after use. NOTE: To prevent damage to the Nintendo DSi, do
not insert anything other than a Nintendo DS licensed stylus into the stylus holder.
Control Buttons [L and R Buttons]
For game play control. See the instructions for the game you are playing for specic control information.
AC Adapter Connector
"MMPXTDPOOFDUJPOPG/JOUFOEP%4J"$"EBQUFSJODMVEFE
for recharging the battery or operation using household current.
Wrist Strap Attachment
'PSBUUBDINFOUPGBXSJTUTUSBQTPMETFQBSBUFMZ
AC Adapter Plug
Plugs into a standard 120-volt AC wall outlet.
DC Connector Plug
Plugs into the AC adapter connector on the back of the Nintendo DSi.
Stylus Tip
'PSVTFPOUIFMPXFSTDSFFO5PVDI4DSFFOPGUIF/JOUFOEP%4J
Camera Indicator LED
Lights when the outer camera is in use.
Outer Camera
Used by games or other applications that use the camera feature.
NOTE: Avoid getting the camera lens dirty. If it becomes dirty, wipe gently with a soft cloth,
being careful not to damage the lens.
DS Game Card Slot
'PSMPBEJOH/JOUFOEP%4JBOE/JOUFOEP%4(BNF$BSETTPMETFQBSBUFMZ
Nintendo DSi (back view) Nintendo DSi AC Adapter Model No. WAP-002(USA)
Nintendo DSi AC Stylus
SEE PAGE 17
SEE PAGE 15
SEE PAGE 11
The system comes with two styluses. One is shipped in the stylus
holder on the side of the system and the other is contained within
the box. Make sure to keep the other stylus as a backup.

Nintendo DS Specifications

General

Platform	Nintendo DS
Internal memory	4 MB
Product color	Pink
Built-in camera	No
Number of built-in speakers	2
Built-in memory capacity	0.25 GB
Display diagonal	3 \
Display resolution	256 x 192 pixels
Headphone outputs	1
Wi-Fi standards	802.11b
Security algorithms	WEP
Battery capacity	850 mAh
Battery life (max)	10 h

Weight and Dimensions

Depth	84.7 mm
Width	148.7 mm
Height	28.9 mm
Weight	275 g
