1 9 17
2 10 18
3 11 19
4 12 Ambient temperature sensor 20
5 13 Water flow switch 21
6 14 22
7 15 23
8 16
High efficiency finned heat exchanger Front plate Middle plate
Left handle Chassis Titanium heat exchanger
Left plate Top cover Pipe component
Motor support Wire controller
Fixed plate Compressor
Fan motor Back net Right handle
Fan blade Electrical box Right plate
Fan motor cover EEV
