Nitecore HC60 V2 User Manual

Contents [ hide
1 Features
2 Specifications
3 Accessories
4 Battery Options
5 Technical Data
6 Charging Function
7 Battery Installation
8 Warranty Service
9 HC60 V2 / HC60W V2
9.1 Charging Function
9.2 Operating Instructions
9.3 On / Off
9.4 Brightness Levels
9.5 Direct Access to ULTRALOW / TURBO
9.6 Special Modes (STROBE / SOS /
BEACON)
9.7 Power Indication
9.8 ATR (Advanced Temperature Regulation)
9.9 Changing Batteries
9.10 Maintenance
10 File Downloads
11 References
12 Related Manuals
Features
Utilizes an OSRAM P9 LED with a max output of 1,200 lumens
Max peak beam intensity of 4,240cd and max throw of 130 meters
An optical system combined with crystal coating and “Precision Digital Optics Technology” (PDOT)
Powered by 1 x 18650 or 2 x CR123 batteries with a max runtime of 680 hours
One switch controls 5 brightness levels and 3 special modes
Highly efficient constant current circuit provides a stable output
The power indicator beneath the switch indicates the remaining battery power (Patent No. ZL201220057767.4)
The power indicator can display the battery voltage ( ±0.1 V)
Built-in Li-ion battery charging circuit with a USB-C port
Wide range flood optic system of 100° illumination angle specially designed for outdoor applications
Incorporated Advanced Temperature Regulation (ATR) module (Patent No. ZL201510534543.6)
180° adjustable tilt angle
Constructed from aero grade1 aluminum alloy
HA III military grade hard-anodized finish
Waterproof rating in accordance with IPX7
Impact resistant to 1 meter
Specifications
Dimensions:
84mmx35.8mm x53.Smm (3.31 “x l.4 l “x 2. l 1 “) (Bracket Included)
Weight:
70g (2.47oz) (Bracket Included, Headband and Battery Not Included)
108.Sg (3.83oz) (Bracket and Headband Included, Battery Not Included)
Accessories
NITECORE 18650 Rechargeable Li-ion Battery (NL1834 3,400mAh), Spare O-ring, USB-C Charging Cable, Spare Switch Cover, Headband, Bracket
Battery Options
Type Nominal Voltage Compatibility
18650 Rechargeable Li-ion Battery (Button Topped) 18650 3.6V/3.7V Y (Recommended)
Primary Lithium Battery CR123 3V Y (Compatible)
Rechargeable Li-ion Battery RCR123 3.6V/3.7V Y (Compatible)
18650 Rechargeable Li-ion Battery (Flat Topped) 18650 ─ N (Incompatible)
Note:
1. The product will NOT work when using a flat topped 18650 battery.
2. DO NOT attempt to use the HC60 V2 / HC60W V2 to charge CR123/RCR123 batteries
Technical Data

Nitecore HC60 V2 Specifications

General

Control type	Buttons
Product color	Black
Flashlight type	Headband flashlight
Housing material	Aluminum
Adjustable headband	Yes
Shockproof up to	1 m
International Protection (IP) code	IPX7
Lamp type	LED
Luminous flux	1200 lm
Lamps quantity	1 lamp(s)
Flashlight modes	Ultralow, High, Low, Medium, SOS mode, Strobe mode, Turbo
Luminous intensity	4240 cd
Number of power levels	5
Light beam distance (max)	130 m
Battery type	18650
Charging source	USB
Battery capacity	3400 mAh
Battery life (max)	680 h
Sustainability certificates	CE
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	53.5 mm
Width	84 mm
Height	35.8 mm
Weight	70 g
