NOAH ACTUATION SA Series - 4. Standard Specification; Specification Summary; 5. Optional Specification & Performance; Optional Modules and Performance Data

5
SA
SERIES MANUAL
4. Standard Specification
5. Optional Specification
6. Performance
C P T
P C U
Current Position Transmiter
Output : DC 4-20mA
SA005L / SA009L
SA005L / SA009L
Proportional Control Unit
Input : DC 4-20mA, DC1-5V, DC2-10V
Output : DC 4-20mA
Local Control Unit
SA005L / SA009L
L C U SA005L / SA009L
Stall Protection
Travel Angel
Space Heater
Enclosure Weatherproof Enclosure IP67 Nema 4 and 6
Ambient Temperature
-20℃ to +70℃ 120℃ / 1hr
DC12V, DC24V, AC24V
Power Supply
AC110 / 220V 50/60Hz
Limit Switches Open / Close + Dry Contact Open / Close
Thermal Protection ( Open 120℃)
90˚±5˚ (Extention : Upto 270˚)
Indicator Dome Type (LED Light Inside)
Manual Operation By L-Wrench (6mm Hexagon)
Self Locking Provided by means of Worm Gearing
5W (110 / 230VAC, 24VDC)
Cable Entries
Two PF 1/2”
Option : M20 Pitch1.5, NPT 1/2”
Lubrication Grease (Shell Gadus S2 V220 2 )
Materials Aluminium Alloy
Surface Treafment Anodizing
External Coating Polyester (TGIC-Free)
P I U Potentiometer 1K Ohm
Model
SA005
SA005L
Output
Torque
Operating Time (90˚) Motor Class (W) Rated Current (A)
1 Phase(AC) DC1 Phase(AC) DC
Duty
Cycle
Number
of
Handle
Turns
Weight
Kg.m N.m in-lb 60Hz 50Hz 24V 110V 220V 24V
S2
(min)
S4
(%)
kg
5 50 14 17 15 1.8 0.35 0.23 1.8 15 2.8
5 50 14 17 15 1.8 0.35 0.23 1.8 15
6
6 3.2
SA009
SA009L
9
9
90
90
26 32
26
434
434
782
782 32
12V
11
11
25
25
24V
10
10
22
22
15
15
6
6
6
6
6
6
6
6
6
6
6
6
15
15
15
15
2.1
2.1
0.35
0.35
0.25
0.25
2.1
2.1
12V
1 Phase(AC) DC
24V 110V 220V 24V
12V
3.2
3.2
3.4
3.4
15
15
50
50
30
30
4.5
4.5
2.8
3.2
lb
6.2
7.1
6.2
7.1
