OPERATION EN
13
Nobles Strive Compact (03--08)
MACHINE SPECIFICATIONS
MODEL Strive Compact
LENGTH 29.5 in / 749 mm with handle fol ded
WIDTH 19.1 in / 485 mm
HEIGHT 27.9 in / 709 mm with handle fol ded
WEIGHT 117lb/53kg
SOLUTION TANK CAPACITY 5 gal / 19 L
RECOVERY TANK CAPACITY 5 gal / 19 L
PRODUCTIVI TY RATE -- AVG. 3,250 ft
2
/ 302 m
2
/hr
CLEANING PA TH WIDTH 15 in/ 380 mm
ROLLER PRESSURE 32 lb/ 14.5 kg
ROLLER MOTOR 120V, .3 hp/ .2 kW, 1.7 A, 450 brush rpm
VACUUM MOTOR 120V, 1.2 hp/ .88 kW, 2--stage 5.7, 7.1 A
WATER LIFT--AIR FLOW 86 in / 2,184 mm
SOLUTION PUMP 120V, 0.11 hp/ 0.081 kW, 2--stage 5.7, 0.7 A
SOLUTION FLOW RATE .2 gal / .76 L/min
VOLTAGE 120 AC
TOTAL POWER CONSUMPTION 11 A
POWERCORDLENGTH 50 ft/15 m
DECIBEL RATING AT OPERATOR’S EAR, INDOORS* 69 dBA
PROTECTION GRADE IPX3
VIBRATI ONS AT CONTROLS <1.8 m/s2
*Sounds levels (ISO 11201) as recommended by the American Association of Cleaning Equipment Manufactures (AACEM) and OSHA.
