Nobles STRIVE COMPACT - Page 49

STANDARD PARTS
Nobles StriveR Compact (04--2012)
7
HANDLE GROUP
Ref. Part No. Serial Number Description Qty.

9005513 (10000000--20000000 ) Handle, Nobles Strive Compact 1
Y
1 9004321 (10000000--20000000 ) Cover, Handle Front/Rear Nobles Sc Kit 1
YY
1 1039088 (10000000--20000000 ) Label, Logo, Handle [Nobles] 1
YY
2 1034592 (10000000--20000000 ) Label, Opertnl, Instrmt Panl, Readyspace 1
Y
3 1038375 (10000000--20000000 ) Gauge, Ammeter, 120vac, 5.0a [Rlr Press] 1
Y
4 602919 (10000000--20000000 ) Switch, Rocker, Dpdt, On / On 1
Y
6 42368 (10000000--20000000 ) Nut, Hex, Std, M4 X 0.70, 8 2
Y
7 140061 (10000000--20000000 ) Washer, Lock, Ext, 08, Pl 2
Y
8 1034952 (10000000--20000000 ) Screw, Hex, M4 X 0.7 X 12, Dbl Thrd 1
Y
9 1043573 (10000000--20000000 ) Screw, #10--14 X 0.675, Spl[Shcs,Selftap] 7
Y
10 130166 (10000000--20000000 ) Grip, Cord, Strainrelief Pg--11 W/Nut Bk 1
Y
11 1042410 (10000000--20000000 ) Cord, 14ga /3, 16.0l, W/ Receptacle, Yel 1
Y
12 1037147 (10000000--20000000 ) Clip, Cord, Strainrelief, Black 1
Y
13 1033893 (10000000--20000000 ) Lever, Cntrl, Switch [Trex] 2
Y
14 9008568 (10000000--20000000 ) Switch Kit, W/ Washers, Fr/ F/1063165 1
Y
15 1034945 (10000000--20000000 ) Lever, Adjmt, Handle 1
Y
16 1036599 (10000000--20000000 ) Cover, Handle, Nobles [T rex] 1
Y
17 1043572 (10000000--20000000 ) Screw , #10--14 X 01.5, Spl[Shcs Selftap] 2
Y
18 1034176 (10000000--20000000 ) Bushing, Flng, 5mmb 12mmd 8mml, Pa6 1
Y
19 1034180 (10000000--20000000 ) Rod, Release [Trex] 1
Y
20 603104 (10000000--20000000 ) Hook, Cord, Blk [Quick--Release] 1
Y
21 603108 (10000000--20000000 ) Spring, Cmpr, Switch 1
Y
22 140239 (10000000--20000000 ) Bolt, Shld, .38d X 1.75, .31--18 1
Y
23 1045239 (10000000--20000000 ) Tube, Assy, Handle 1
Y
24 1013295 (10000000--20000000 ) Spring, Cmpr [2100 Series] 1
Y
25 9006059 (10000000--20000000 ) Plunger Kit, Handle 1
Y
26 1034924 (10000000--20000000 ) Pin, Roll, 04mmd X 40mml 1
Y
27 1016399 (10000000--20000000 ) Screw , Hex, M8 X 1.25 X 30, Nl, Ss 4
Y
28 140027 (10000000--20000000 ) Washer, Flat, 0.35b 0.75d .04, Ss 4
Y
29 49609 (10000000--20000000 ) Screw , Soc, M8 X 1.25 X 16, 12.9 4
Y
30 1000307 (10000000--20000000 ) Handle, Pivot, Half 2
Y
31 1034155 (10000000--20000000 ) Pin, Roll, 06mmd X 36mml 2
Y
32 1034872 (10000000--20000000 ) Gear , Lock, Handle 1
Y
33 612422 (10000000--20000000 ) Seal, Org, Gear Seat 2
34 1042403 (10000000--20000000 ) Cord, Power, 1.5mm /3 Yel[2x15m 50ft Us] 1
 ASSEMBLY
Y INCLUDED IN ASSEMBLY
