STANDARD PARTS
Nobles StriveR Compact (04--2012)
9
FRAME GROUP
Ref. Part No. Serial Number Description Qty.
1 1064038 (10000000--20000000 ) Gauge, Hourmeter , 05--277 Volt, Ac / Dc 1
2 86726 (10000000--20000000 ) Grommet, Rbr, 0.44id, F/0.5h, .19 Matl 1
3 1032018 (10000000--20000000 ) Module, Timer , 120vac [Trex Readyspace] 1
4 01683 (10000000--20000000 ) Washer, Flat, 10, Ss 1
5 09739 (10000000--20000000 ) Nut, Hex, Lock, M5 X 0.80, Nl, Ss 1
6 383720 (10000000--20000000 ) Circuitbreaker, 05.0a, Resetable 1
7 383722 (10000000--20000000 ) Circuitbreaker, 15.0a, Resetable 1
8 74027 (10000000--20000000 ) Screw, Pan, Phl, M6 X 1.00 X 12, Nl, Pl 1
9 9004275 (10000000--20000000 ) Cover Kit, Column , W/ Label [5gal 120v] 1
Y
10 NA (10000000--20000000 ) Label, Safety, 120vac [Etl] 1
Y
11 1039105 (10000000--20000000 ) Label,W arning,Ac Scrb/Extr [En/Fr/Es/Jp] 1
12 1044427 (10000000--20000000 ) Nut, Hex, Lock, #8--32, Nl, Ss 1
13 41578 (10000000--20000000 ) Washer , Flat, 06, Ss 1
14 02938 (10000000--20000000 ) Washer , Lock, Int, 08, Ss 1
15 9004274 (10000000--20000000 ) Column Kit, Sppt, W/ Label [5 Gal] 1
16 1015852 (10000000--20000000 ) Screw , Hex, M8 X 1.25 X 25, Nl, Fl, Ss 4
17 140027 (10000000--20000000 ) Washer, Flat, 0.35b 0.75d .04, Ss 4
18 1031418 (10000000--20000000 ) Cover, Frame, Rear [T rex] 1
19 1014918 (10000000--20000000 ) Wheel, 03.0d 0.88w 0.31b, W/ Bshg, Rbr 2
20 1035139 (10000000--20000000 ) Ring, Retaining, Ext, 0.31d, E--Type 2
21 1035137 (10000000--20000000 ) Pin, Clevis, Grvd 0.31d X 2.00l, Ss 2
22 1039073 (10000000--20000000 ) Wheel Assy, 8.0d 2.0w 0.5b W/Brg 2
23 1038770 (10000000--20000000 ) Washer, Flat, 0.50b 0.75d 0.06, Ss 2
24 1033757 (10000000--20000000 ) Bolt, Shld, .50 X 3.25, .38--16, Ss 2
25 33925 (10000000--20000000 ) Washer , Flat, M12, Ss 2
26 01685 (10000000--20000000 ) Washer , Flat, 0.38b 0.88d .08, Ss 3
27 1031527 (10000000--20000000 ) Frame (Machined) 1
28 1019349 (10000000--20000000 ) Screw , Trs, M6 X 1.00 X 16, Ss, Sems 2
29 1051665 (10000000--20000000 ) Bracket, Adjustment, Head 1
30 1036668 (10000000--20000000 ) Bumper , Front 1
31 08714 (10000000--20000000 ) Nut, Hex, Lock, M10 X 1.5, Nl, Ss 1
32 1051666 (10000000--20000000 ) Adjuster, Roller 1
33 09162 (10000000--20000000 ) Screw, Set, Soc, M6 X 1.00 X 8, Nl 1
34 1035496 (10000000--20000000 ) Bracket, Roller 1
35 1035519 (10000000--20000000 ) Bar, Rnd, Stl, 0.31d X 4.09l, 2cham 1
36 605317 (10000000--20000000 ) Roller, Sqge, 1.35od X 1.48l [Delrin] 2
37 1036002 (10000000--20000000 ) Knob, Adj, M10 X50 Stud, Blk 1
38 08713 (10000000--20000000 ) Nut, Hex, Lock, M8 X 1.25, Nl, Ss 1
39 49826 (10000000--20000000 ) Screw , Hex, M8 X 1.25 X 16, Nl, Ss 2
40 1014918 (10000000--20000000 ) Wheel, 03.0d 0.88w 0.31b, W/ Bshg, Rbr 1
41 1034805 (10000000--20000000 ) Bracket, Bumper Wheel 1
42 48732 (10000000--20000000 ) Screw, Pan, Phl, M6 X 1.00 X 10, Ss 1
43 140016 (10000000--20000000 ) Washer, Lock, Split, 0.25, Ss 1
44 1020341 (10000000--20000000 ) Screw , Hex, M8 X 1.25 X 20, Ss, Sems 4
N/S 1033926 (10000000--20000000 ) Harness, Chassis, Ele [T--Rex Readyspace] 1
ASSEMBLY
Y INCLUDED IN ASSEMBLY
N/S = NOT SHOWN
