STANDARD PARTS
Nobles StriveR Compact (04--2012)
13
TANK COVER GROUP
Ref. Part No. Serial Number Description Qty.
1 1037759 (10000000--20000000 ) Cover , Tanks, Upper, Nobles [Trex] 1
2 1035358 (10000000--20000000 ) Pin, Grvd, 0.375d, 1.25l 2
3 24555 (10000000--20000000 ) Ring, Retaining, Ext, 0.38d, [E--Ring] 2
4 1016399 (10000000--20000000 ) Screw, Hex, M8 X 1.25 X 30, Nl, Ss 4
5 140027 (10000000--20000000 ) Washer, Flat, 0.35b 0.75d .04, Ss 4
6 1034346 (10000000--20000000 ) Bracket, Pivot, Cover, Mtg 1
7 1036063 (10000000--20000000 ) Hose, Soltn, .25 Id, .453 Od, 56.0 L 1
8 140340 (10000000--20000000 ) Screw, Pan, Phl, 10--24 X 0.62, Ss[Typ25] 13
9 1042715 (10000000--20000000 ) Fitting, Brs, Str, Bm04/Pm02 1
10 1032556 (10000000--20000000 ) Filter, Soltn Tube, 80 Mesh 1
11 140011 (10000000--20000000 ) Washer, Flat, 0.21b 0.45d .03, Ss 2
12 1051274 (10000000--20000000 ) Gasket, Shield, Float 1
13 1042277 (10000000--20000000 ) Shield, Float 1
14 1044370 (10000000--20000000 ) Ball, Float, W/O Cage 1

15 9005924 (10000000--20000000 ) Cover, Tank, Inner W/ Seals, Kit 1
Y
16 1036090 (10000000--20000000 ) Seal, Vacuum [Trex] 2
Y
17 1052876 (10000000--20000000 ) Gasket, Tank 2
Y
18 602849 (10000000--20000000 ) Strainrelief, Cord, Ele, Pm08, Blk Nyl 1
19 1035866 (10000000--20000000 ) Hose, Recvy, Formed [Trex] 1
20 1037756 (10000000--20000000 ) Hose, Vacuum, 1.5od, 18.0l [Wire--Reinf] 1
21 140308 (10000000--20000000 ) Clamp, Hose, Wormdrive, 1.31--2.25d, .50w 4
22 1054345 (10451589--20000000 ) Clip, Retaining, Seal 2
 ASSEMBLY
Y INCLUDED IN ASSEMBLY
