STANDARD PARTS
Nobles StriveR Compact (03--2009)
15
VACUUM FAN GROUP
Ref. Part No. Serial Number Description Qty.
1 1031960 (10000000--20000000 ) Plate, Mtg, Vacuum 1
2 1026454 (10000000--20000000 ) Screw, Pan, Phl, M5 X 0.80 X 10, Ss 3
3 610144 (10000000--20000000 ) Spacer , Fan 2
4 1032555 (10000000--20000000 ) Hose, Vacuum, 1.50id X 19.5l, 2cuff, Clr 1
5 1038373 (10000000--20000000 ) Hose, Vacuum, Wir, 38.0id X 490.0l, Clr 1
6 79381 (10000000--20000000 ) Clamp, Hose, Wormdrive, 1.25--2.00d, .50w 4
7 1038379 (10000000--20000000 ) Hose, Vacuum, Wir , 38.0id X 335.0l, Clr 1
8 08708 (10000000--20000000 ) Nut, Hex, Lock, M6 X 1.00, Nl 2
9 1050092 (10000000--20000000 ) Manifold, Soltn, Wand [Trex] 1
10 09258 (10000000--20000000 ) Screw , Pan, Phl, M6 X 1.00 X 40, 4.8 2
11 607183 (10000000--20000000 ) Seal, Cap, Vacuum Tool [607170] 1
12 140801 (10000000--20000000 ) Screw , Trs, Phl, 08--32 X 0.38, Ss 1
13 140011 (10000000--20000000 ) Washer, Flat, 0.21b 0.45d .03, Ss 1
14 09007 (10000000--20000000 ) Screw, Hex, M6 X 1.00 X 25, Ss 2
15 01684 (10000000--20000000 ) Washer, Flat, 0.27b 0.69d .05, Ss 6
16 08708 (10000000--20000000 ) Nut, Hex, Lock, M6 X 1.00, Nl 4
17 1034069 (10000000--20000000 ) Plate, Vac Mounting 1
18 630010 (10000000--20000000 ) Gasket, 12.7mm Th, 43mmid 73mmod 1
19 1037541 (10000000--20000000 ) Fan, Vacuum, 5.7d, 120 Vac, 2 Stage 1
20 130773 (10000000--20000000 ) Tie, Cable, Nyl, 11.0l, .14w, 3.0 Max. D 1
21 600009 (10000000--20000000 ) Muffler , Exhaust, Vacfan 1
