Nobles STRIVE COMPACT - Page 59

STANDARD PARTS
Nobles StriveR Compact (04--2012)
17
SOLUTION GROUP
Ref. Part No. Serial Number Description Qty.
1 08712 (10000000--20000000 ) Nut, Hex, Lock, M6 X 1.00, Nl, Ss 2
2 01684 (10000000--20000000 ) Washer, Flat, 0.27b 0.69d .05, Ss 2
3 150417 (10000000--20000000 ) Fitting, Plstc, E90, Bm04/Pm06 2
4 1031915 (10000000--20000000 ) Pump, Soltn, Ele, 110vac 1
5 43844 (10000000--20000000 ) Clamp, Hose, Wormdrive, 0.25--0.62d, .31w 15
6 1034331 (10000000--20000000 ) Bracket, Pump 1
7 140874 (10000000--20000000 ) Screw, Hex, 10--32 X 0.38, Pl [Inwa Ty1] 2
8 606364 (10000000--20000000 ) Hose, Pvc, Brd, 0.25id 0.50od 60.0l,Gray (160204) 1
9 150515 (10000000--20000000 ) Fitting, Brs, Str, Bm04/Pm04 [Taped] 2
10 1028773 (10000000--20000000 ) Fitting, Brs, E90, Bm04/Pf04 1
11 32486 (10000000--20000000 ) Washer, Flat, 0.50, Sae 1
12 1033445 (10000000--20000000 ) Shroud, Splash, Nozzle [T rex] 1

13 1061033 (10000000--20000000 ) Nozzle Assy, Spray [1/4qjja+Qtka--1]] 1
Y
14 1034685 (10000000--20000000 ) Nozzle, Tip, Spray [Qtka] 1
15 41579 (10000000--20000000 ) Washer , Flat, 08, Ss 2
16 579237 (10000000--20000000 ) Screw, Pan, Phl, M4 X 0.70 X 12, Ss 2
17 150713 (10000000--20000000 ) Fitting, Plstc, Tee, Bm04/Bm04/Bm04 1
18 1037846 (10000000--20000000 ) Manifold, Soltn, 120 V olt 1
19 01683 (10000000--20000000 ) Washer , Flat, 10, Ss 2
20 07514 (10000000--20000000 ) Washer , Lock, Int, 10, Ss 2
21 140841 (10000000--20000000 ) Screw , Pan, Phl, 10--32 X 0.62, Ss 2
22 150418 (10000000--20000000 ) Fitting, Brs, E90, Bm04/Pm04 1
23 150525 (10000000--20000000 ) Fitting, Brs, Str, Bm04/Pm02 1
24 150402 (10000000--20000000 ) Fitting, Brs, E90, Pf02/Pf02 1
25 3148.816 (10000000--20000000 ) Washer, Flat, 0.52b 0.88d .06, Stl, Pl 1
26 150915 (10000000--20000000 ) Fitting, Brs, Qdc, Pm02, Fem [Ser 5] 1
27 606161 (10000000--20000000 ) Hose, Pvc, Brd, 0.25id 0.50od 36.0l,Gray (160204) 1
28 150713 (10000000--20000000 ) Fitting, Plstc, Tee, Bm04/Bm04/Bm04 1
29 1035296 (10000000--20000000 ) Washer, Flat, Belleville, .567 1
 ASSEMBLY
Y INCLUDED IN ASSEMBLY
 ASSEMBLY
Y INCLUDED IN ASSEMBLY
