STANDARD PARTS
Nobles StriveR Compact (07--2010)
19
SCRUB HEAD GROUP
Ref. Part No. Serial Number Description Qty.
1 1045325 (10000000--20000000 ) Screw, Hex, M6 X 1.00 X 45, Ss 8
2 1027144 (10000000--20000000 ) Washer, Lock, Int, M6, Ss 8
3 01684 (10000000--20000000 ) Washer, Flat, 0.27b 0.69d .05, Ss 8
4 1054903 (10000000--20000000 ) Housing, Brush, Dbl, 40cm 1

5 9007963 (10000000--20000000 ) Door Kit, Brush, W/ Hdwr 1
Y
6 1019349 (10000000--20000000 ) Screw, Trs, M6 X 1.00 X 16, Ss, Sems 2
Y
7 1030682 (10000000--20000000 ) Shaft, Idler Plug 2
Y
8 1030680 (10000000--20000000 ) Hub, Idler , Brush 2
Y
9 01543 (10000000--20000000 ) Ring, Retaining, Ext, 0.39d, Basic 2

10 1035298 (10000000--20000000 ) Motor, .25hp, 115vdc, 2.1a, 1550 Rpm 2
Y
11 1045465 (10000000--20000000 ) Brush, Carbon (Pk=2) Ref Part 1035298 4
12 09162 (10000000--20000000 ) Screw, Set, Soc, M6 X 1.00 X 8, Nl 4
13 1030623 (10000000--20000000 ) Sheave, 07grv, 16.03pd [Ph] 2
14 01684 (10000000--20000000 ) Washer , Flat, 0.27b 0.69d .05, Ss 4
15 07515 (10000000--20000000 ) W asher, Lock, Int, 0.25, Ss 4
16 34323 (10000000--20000000 ) Screw , Hex, .25--20 X 0.75, Nl 4
17 1037928 (10000000--20000000 ) Cover, Belt, Spg (Dual Roller) 1
18 1019349 (10000000--20000000 ) Screw, Trs, M6 X 1.00 X 16, Ss, Sems 2
19 140946 (10000000--20000000 ) Screw, Rnd, Sltd, 06--32 X 1.00, Nyl 1
20 140534 (10000000--20000000 ) Nut, Hex, #06--32, Nyl 1
21 1028953 (10000000--20000000 ) Roller Assy, Readyspace 2
22 386868 (10000000--20000000 ) Screw, Hex, M8 X 1.25 X 12, Ss 1
23 07515 (10000000--20000000 ) W asher, Lock, Int, 0.25, Ss 1
24 1042443 (10000000--20000000 ) Support, Kickstand, Blk, Nyl 1
25 140060 (10000000--20000000 ) Washer .505x.750x.045 Wave 1
26 08712 (10000000--20000000 ) Nut, Hex, Lock, M6 X 1.00, Nl, Ss 3
27 15678 (10000000--20000000 ) Screw, Hex, M6 X 1.00 X 16, Ss 3
28 9004280 (10000000--20000000 ) Bracket, Motor Mount W/ Bearing/Seal Kit 1
29 9004282 (10000000--20000000 ) Belt Kit, W/ Installation Tool [Qty 2] 1
30 130288 (10000000--20000000 ) Rectifier, Bridge, Rnd, 12a 1000volt, Ce 1
 ASSEMBLY
Y INCLUDED IN ASSEMBLY
