ORDERING
Ordering
Obsolete
It is recommended to replace the 2011KCI and
2211KCI by more advanced 2012KCI, which has
been available since spring 2007.
Order code
Example: 1000F4 – 2011KCI – 230VAC
The order code consists of several parts. The first
part describes the large display type, the next part
defines the input card type, and the last part
selects the supply voltage.
Large display type
Nokeval has four cases for large field displays.
These are:
575 Five 57 mm digits, plastic enclosure
1000 Three to four 100 mm digits, steel
1100 Five to six 100 mm digits, steel
1800 Three to five 180 mm digits, steel
The letter after the case size is either E or F. This
tells the type of the internal electronics. They are
principally the same but have different looks. The
main difference is that the input card is upside
down in the E chassis. Since beginning of year
2003 all displays have been with F chassis.
The number after the letter defines the number of
display digits.
Input card type
These large displays use Nokeval 2000 series
input cards. Custom input cards 2011KCI and
2211KCI have been designed for KCI.
Power supply options
Before summer 2009, the large field displays have
been available with three power supply options:
Name Voltages
-24VDC 24 VDC
-48VAC 48 VDC or VAC
-230VAC 115 or 230 VDC or VAC
After summer 2009, the input voltage range of the
230 VAC model has been extended to cover the
range 41...265 VDC/AC, removing the need for a
separate 48 VAC model. The voltage options are:
Name Voltages
-24VDC 24 VDC
-48/230VAC 48, 115, or 230 VDC or VAC
Common models
1000F4-2011KCI-48/230VAC: four 100mm digits,
1 input, power 48 to 230 VAC.
1000F4-2211KCI-48/230VAC: four digits, 2 inputs,
power 48 to 230 VAC.
Spare parts ordering
Spare input card:
2011KCI-IN
2211KCI-IN
Spare electronics unit including input card:
SP-EL2011KCI-48/230VAC (or whichever
supply and cards)
Spare ribbon cable from el unit to large digits:
SP-CA-EL1000F
Spare large digit:
SP-100DISP (100 mm digit)
3
