Nokia 1616 Service Manual

Nokia 1616
RH-125/RH-126
Service Manual Level 1&2
3
Confidential
 Copyright © 2010 Nokia  All rights reserved
Version 2.0 ISSUE 2
1. CHANGE HISTORY
Status Version No. Date Comments
First approved version 1.0 23.12.2009
Approved 2.0 6.4.2010 Flash concept updated
The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to
carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA
service suppliers, and the content of it is confidential. Please note that NOKIA provides also other
guidance documents (e.g. Service Bulletins) for service suppliers, follow these regularly and
comply with the given instructions.
While every endeavor has been made to ensure the accuracy of this document, some errors may
exist. If you find any errors or if you have further suggestions, please notify NOKIA using the
address below:
Nokia Care Academy
mailto:Service.Manuals@nokia.com
Please keep in mind also that this documentation is continuously being updated and modified,
so watch always out for the newest version.

Nokia 1616 Specifications

General

Display type	TFT
Display diagonal	1.8 \
Display resolution	128 x 160 pixels
Display number of colors	65536 colors
Internal memory	- MB
Networking type	EGSM/GSM
Operating frequency	1900/1800/900/850 MHz
FM radio	Yes
Ringer type	Polyphonic
Audio formats supported	mp3
Polyphonic rings quantity	32
Product color	Black
Battery type	BL-5CB
Talk time (2G)	8.52 h
Battery capacity	800 mAh
Standby time (2G)	540 h
SIM card capability	Single SIM
Form factor	Bar
Phonebook capacity	500 entries
Personal info management (PIM)	Alarm clock, Calendar
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network

Weight and Dimensions

Depth	107.1 mm
Width	45 mm
Height	15 mm
Weight	78.55 g
