Nokia 1616 Service Manual

Nokia 1616
RH-125/RH-126
Service Manual Level 1&2
6
Confidential
 Copyright © 2010 Nokia  All rights reserved
Version 2.0 ISSUE 2
4. ESD PROTECTION
Nokia requires that service points have sufficient ESD protection (against static
electricity) when servicing the phone.
Any product of which the covers are removed must be handled with ESD
protection. The SIM card can be replaced without ESD protection if the product
is otherwise ready for use.
To replace the covers ESD protection must be applied.
All electronic parts of the product are susceptible to ESD. Resistors, too, can be
damaged by static electricity discharge.
All ESD sensitive parts must be packed in metallized protective bags during
shipping and handling outside any ESD Protected Area (EPA).
Every repair action involving opening the product or handling the product
components must be done under ESD protection.
ESD protected spare part packages MUST NOT be opened/closed out of an ESD
Protected Area.
For more information and local requirements about ESD protection and ESD
Protected Area, contact your local Nokia After Market Services representative.

Nokia 1616 Specifications

General

Display type	TFT
Display diagonal	1.8 \
Display resolution	128 x 160 pixels
Display number of colors	65536 colors
Internal memory	- MB
Networking type	EGSM/GSM
Operating frequency	1900/1800/900/850 MHz
FM radio	Yes
Ringer type	Polyphonic
Audio formats supported	mp3
Polyphonic rings quantity	32
Product color	Black
Battery type	BL-5CB
Talk time (2G)	8.52 h
Battery capacity	800 mAh
Standby time (2G)	540 h
SIM card capability	Single SIM
Form factor	Bar
Phonebook capacity	500 entries
Personal info management (PIM)	Alarm clock, Calendar
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network

Weight and Dimensions

Depth	107.1 mm
Width	45 mm
Height	15 mm
Weight	78.55 g
