Nokia 1616 Service Manual

Nokia 1616
RH-125/RH-126
Service Manual Level 1&2
2
Confidential
 Copyright © 2010 Nokia  All rights reserved
Version 2.0 ISSUE 2
Contents
1. Change history ............................................................................................................................................................................... 3
2. Copyrig ht .......................................................................................................................................................................................... 4
3. Warnings and cautions ............................................................................................................................................................... 5
3.1 Warnings ................................................................................................................................................................................ 5
3.2 Cautions .................................................................................................................................................................................. 5
4. ESD protection ................................................................................................................................................................................ 6
5. Care and maintenance ................................................................................................................................................................ 7
6. Battery information ..................................................................................................................................................................... 8
7. Exploded view ................................................................................................................................................................................ 9
8. Service devices .............................................................................................................................................................................10
9. SW-update .....................................................................................................................................................................................11
10. Disassembly instructions .....................................................................................................................................................12
11. Assembly HINTS.......................................................................................................................................................................15
12. Solder components ................................................................................................................................................................16


Nokia 1616 Specifications

General

Display type	TFT
Display diagonal	1.8 \
Display resolution	128 x 160 pixels
Display number of colors	65536 colors
Internal memory	- MB
Networking type	EGSM/GSM
Operating frequency	1900/1800/900/850 MHz
FM radio	Yes
Ringer type	Polyphonic
Audio formats supported	mp3
Polyphonic rings quantity	32
Product color	Black
Battery type	BL-5CB
Talk time (2G)	8.52 h
Battery capacity	800 mAh
Standby time (2G)	540 h
SIM card capability	Single SIM
Form factor	Bar
Phonebook capacity	500 entries
Personal info management (PIM)	Alarm clock, Calendar
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network

Weight and Dimensions

Depth	107.1 mm
Width	45 mm
Height	15 mm
Weight	78.55 g
