Service Manual Level 1 and 2
Nokia 206 Dual SIM/2060, Nokia 206
RM-872, RM-873
Version 1.0
Solder components
V2403
F2051
X7454
V2404
X7453
LED
LED
Charger
fuse
Antenna
GND spring
Antenna
spring
BOTTOM
v1.0
©2012 Nokia | Nokia Internal Use Only | All Rights Reserved.
