Nokia 206 Dual SIM Service Manual

Service Manual Level 1 and 2
Nokia 206 Dual SIM/2060, Nokia 206
RM-872, RM-873
Version 1.0
Product controls and interfaces
2
3
4
5
6
1
15
16
7
89
10
11
12
14
13
14 — SIM Card slot (Dual SIM)
15 — Loudspeaker
16 — Antenna area
9 — Power/End key
8 — Call key
7 — Right selection key
6 — Left selection key
5 — Scroll key
4 — Display
3 — Earpiece
2 — Nokia AV 3.5 mm connector
1 — Charger connector
10 — Alphanumeric keypad
11 — Microphone
12 — Battery cover release notch
13 — Camera
v1.0
©2012 Nokia | Nokia Internal Use only | All Rights Reserved.

Nokia 206 Dual SIM Specifications

General

Brand	Nokia
Model	206 Dual SIM
Category	Cell Phone
Language	English
