Nokia 2710 Service Manual

Nokia 2710 Navigation Edition
RM-586
Service Manual Level 1&2
6
Confidential
 Copyright © 2010 NOKIA  All rights reserved
Version 1.0 ISSUE 1
3. ESD PROTECTION
Nokia requires that service points have sufficient ESD protection (against static
electricity) when servicing the phone.
Any product of which the covers are removed must be handled with ESD
protection. The SIM card can be replaced without ESD protection if the product
is otherwise ready for use.
To replace the covers ESD protection must be applied.
All electronic parts of the product are susceptible to ESD. Resistors, too, can be
damaged by static electricity discharge.
All ESD sensitive parts must be packed in metallized protective bags during
shipping and handling outside any ESD Protected Area (EPA).
Every repair action involving opening the product or handling the product
components must be done under ESD protection.
ESD protected spare part packages MUST NOT be opened/closed out of an ESD
Protected Area.
For more information and local requirements about ESD protection and ESD
Protected Area, contact your local Nokia After Market Services representative.

Nokia 2710 Specifications

General

Network Technology	GSM
2G bands	GSM 900 / 1800
GPRS	Class 10
Status	Discontinued
Weight	87 g
SIM	Mini-SIM
Display type	TFT, 256K colors
Display resolution	240 x 320 pixels, 4:3 ratio (~182 ppi density)
Phonebook	1000 entries
Call records	20 dialed, 20 received, 20 missed calls
Camera	2 MP
Loudspeaker	Yes
3.5mm jack	Yes
WLAN	No
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Messaging	SMS, MMS, Email, IM
Browser	WAP 2.0/xHTML, HTML
Java	Yes, MIDP 2.1
Battery	Removable Li-Ion 1020 mAh battery (BL-5C)
Talk time	Up to 4 h 30 min
Display size	2.2 inches, 15.0 cm2
Memory Card slot	microSD
Alert types	Vibration, MP3 ringtones
Bluetooth	A2DP
Games	Yes
Colors	Black, White
