Nokia 5000 - Page 13

13
CONFIDENTIAL
Copyright © 2008 NOKIA. All rights reserved.
5000 RM-362/RM-363
Page (14) ISSUE 1
Service Manual Level 1&2
17. Remove the CAMERA KEY. 18. Carefully remove the VIBRA MOTOR. Avoid damaging the
gasket.
19. Remove the adhesive residues from the D-COVER. 20. The B-DECO COVER is glued onto the D-COVER. Carefully
unlock the clips from the B-DECO COVER.
21. Use the SS-93 as a lever to remove the B-DECO COVER. 22. Remove the ADHESIVE residues and discard it.
