9. Insert the CAMERA MODULE into its housing. Push it into its
place slightly. Do not touch the lens.
10. Check the camera window for cleaness.
Insert the CAMERA FLEX MODULE into its compartment.
11. Close the ex connector of the camera. 12. Check that all keys operate before going on.
13. Remove the protective lm from the EARPIECE. 14. Insert the EARPIECE into its compartment.
15. Push it down carefully. Never push down the metal part,
otherwise the EARPIECE could be destroyed.
16. Align the LCD to the top guide. Smooth it down evenly.
