N5700 RM-230 / RM-302
Page (53) ISSUE 2
Service Manual Level 1&2
13. Remove the JOYSTICK COVER.
14. Gently unlock the ANTENNA ASSY hooks...
15. ... release hooks also on both sides of the ANTENNA ASSY.
16. Remove the ANTENNA ASSY.
17. Now, open the unit.
18. Undo the screws in the order shown...
